The Ventrac KL480 Tiller features 24 high-carbon steel tines, delivering a 48-inch working width and a maximum tilling depth of 6 inches, making it ideal for preparing garden and yard soil.
Designed with a sealed, lubricated final drive and adjustable skid shoes, the KL480 Tiller ensures smooth operation and precise depth control for consistent soil preparation.
The KL480 Tiller is a versatile attachment that effortlessly turns tough soil into a smooth, plant-ready surface, making garden prep faster and easier for contractors and private property managers alike.
Preparing a new garden plot becomes effortless with the KL480 Tiller, as it breaks up compacted soil and incorporates organic matter for improved plant growth.
Landscapers benefit from the KL480 Tiller's ability to prepare flower beds and landscaping areas quickly, allowing for efficient project completion.
Transforming an overgrown area into a productive food plot is simplified with the KL480 Tiller, effectively turning hard soil into a soft, airy base perfect for planting.
The KL480 Tiller excels at removing weeds and debris, creating a clean seedbed for new plantings in both residential and commercial landscaping projects.
Offer an extra spring service for clients by prepping vegetable gardens with the KL480 Tiller, turning over soil efficiently to create the perfect planting bed.
The KL480 Tiller is designed for easy preparation of gardens and yards. This power-driven front-end attachment allows the operator to easily monitor the Tiller's performance. Designed with the Ventrac Mount System, the Tiller can be attached in a minute or less and comes with a stand for storing the Tiller when not in use.
A number 80 chain in an enclosed final drive is lubricated for heavy-duty performance. Skid shoe adjustments facilitate cutting depth. Twenty-four high carbon steel tines are sequentially spaced to provide smooth and efficient tillage.
Simple Start | KL480
https://www.ventrac.com/ The Ventrac KL480 Tiller is a power-driven front-end attachment that allows the operator to easily monitor performance with its out-front design while preparing yard and garden soil. The Ventrac Tiller offers extraordinary advantages over a walk-behind tiller, such as productivity, safety, and maneuverability.
Whether you are establishing new garden areas or soil for other plant and landscape features, the Ventrac Tiller attachment is sure to be the most capable and easiest solution for the job. The KL480 Tiller creates deeper tillage and loose soil that is best for planting vegetable crops or preparing flower beds.
The KL480 attachment by Ventrac is different than most because it goes on the front of the machine, connected by the front hitch arms, which makes it visible for smooth operation and precision. The Tiller can be attached in less than a minute and comes with a stand for storing when not in use.
The Tiller excels at maneuverability because the tractor is articulated, allowing the operator to get into tighter areas that might otherwise only be accessible with a walk-behind tiller. Walk-behind units are much slower and dangerous while sitting on the Ventrac proves to be less labor-intensive and much more productive.
With a working width of 48 inches and a maximum working depth of 6 inches below grade, the 24 individually replaceable hardened steel tines are sequentially spaced to provide smooth and efficient tillage. Skid shoe adjustments facilitate the cutting depth of the implement and allow for consistent results.
Products featured in this video: VENTRAC 4500: https://www.ventrac.com/products/tractors/4500 KL480 TILLER: https://www.ventrac.com/products/attachments/kl480
For more information, visit https://www.ventrac.com/
Find a dealer near you! https://www.ventrac.com/dealers
Get a FREE catalog! https://www.ventrac.com/contact/catalog
Subscribe here! https://www.youtube.com/channel/UC0aiC7V2JS3nh11R5tRuIUw
Connect with Us! Facebook - https://www.facebook.com/ventrac/ Instagram - @ventrac_tractors Twitter - @ventrac
I'm Aaron Graber with ventrac and in this video we'll go over the tiller. The tiller is really designed for preparing garden areas or prepping soil for other planted landscape features. So when you're talking about the tiller it's gonna be kept mostly to deeper tillage where you're trying to have loose soil where you plant something into. Especially food vegetable crops. Or in flower beds. Something that needs a looser soil to start. When it comes to the ventrac tiller the advantages are productivity safety and maneuverability. Since the tractor is articulated you can get into tighter areas that you might otherwise only be able to access with a walk-behind tiller. And obviously that's going to be much slower and much more dangerous than sitting on the seat of the ventrac This tiller has a working with of 48 inches and a maximum working depth of 6 inches below grade. It has 24 individually replaceable hardened steel tines. Our tiller is a little bit different than most tillers because it goes on the front of the machine. It connects to the front hitch arms of the tractor and is run off the belt driven PTO. There is one trick for attaching and detaching the tiller. The simplest way to think about it is the kickstand that's on the back needs to be up when the tiller is on the tractor and in operation. And down when the tiller is on the ground off of the tractor. So to run this tiller you'll be driving in reverse. You'll want to run this tiller in the float position with the SDLA lever. And also with weight transfer completely off. Once you turn the PTO on the tines will start moving. At that point you can run the RPMs up to maximum rpms and the faster you run the tractor the faster the tines will move. There's only one adjustment that you might make and that's the depth adjustment. You can change that by changing the height of the skid shoes on the left and right of the tiller. As another reminder when you're done using the ventrac tiller just like most of our attachments it'll come off the tractor in just a few seconds and you can be on to the next attachment under a minute. Thank you for watching this video on the ventrac tiller. For information on pricing or other product details make sure to visit our website at ventrac com and also be sure to check out our other videos on our youtube channel.
Base Specifications
| Info | |
|---|---|
|
Product Image
|
|
|
Model
|
|
|
Description
|
Tiller
|
|
Product Type
|
|
|
Sku
|
39.55220
|
|
Price
|
$4,525
|
| General | |
|
Max Till Depth
|
6in
15.24cm
|
|
Ground Clearance
|
Approx
Approx
|
| Dimensions | |
|
Front Mount
|
|
|
4000 Series Mount
|
|
| Dimensions | |
|
Length
|
41in
104.1cm
|
|
Overall Width
|
53in
134.6cm
|
|
Height
|
22in
55.88cm
|
|
Weight
|
356lb
161.5kg
|
|
Working Width
|
48in
121.9cm
|
|
Length with KT Tractor
|
113.3in
287.7cm
|
